LAN-KABEL CAT.5E UTP 305M SOLID CU GRÅ CPR + FLUKE GODKÄND

Tillverkarens kod: LCU5-11CU-0305-S
EAN: 5901969421781
Garanti: 24m
IKT-kategori: Kat. 5/5e
Typ av skärmning: U/UTP
Material för ledare: Koppar (CU)
Material för beläggning: PVC
Produktbeskrivning
- LAN cable category 5e UTP (Unshielded).
- Length 305m.
- The wires are made of pure copper (CU 100% copper).
- AWG 24 (4*2*0.50mm).
- Conductor stranding: single wire.
- Color: PANTONE COOL GRAY 5C.
- Printed length counter at every meter of cable.
- External PVC insulation: 5.0mm.
- HDPE conductor insulation: 0.88mm.
- Operation up to 100Mhz.
- Recommended connector / guide diameter for braided cables: 1.0 mm.
- Package: Color inner box with master carton.
- Packaging dimensions (W x D x H): 36.5x36.5x43.5 cm.
(Inner box dimension: 35x35x21 cm)

Electrical characteristics (20 degrees):

- direct-current resistance: ?9.1?/100m
- Pair-to-Ground capacitance: ?160PF / 100m.
- Characteristic impedance: 100?±15.
- Transport and storage temperature: 0 - 60 degrees.
- Operating temperature: -20 - 75 degrees.
- Working distance: 100m.

IKT-kategori
Kat. 5/5e
Typ av skärmning
U/UTP
Material för ledare
Koppar (CU)
Material för beläggning
PVC
Kategori för reaktion vid brand (Euroclass)
Eca
Ledarens struktur
Enkel trad
Ledarens tjocklek
0.5 mm
AWG
24
HDPE-isolering
0.9 mm
Eftersläpande tjocklek
0.55 mm
Yttre diameter
5.2 mm
Maximal arbetsfrekvens
100 MHz
Längd pa kabel
305 m
Färg
Gra
Temperaturomrade under användning
-20 - 75 °C

Ladda ner filer

Fluke test
Declaration of performance (DOP)
Deklaracja właściwości użytkowych (DWU)
Produktkort PL.
Produktkort EN.
Försäkran om överensstämmelse (flerspråkig)
